DKS Water-bath Type Infusion Bottle Sterilizer
This series adopts high temperature circulating water as sterilization medium, and carry out water-pouring sterilizing operation for articles via warming up, sterilizing and cooling. The equipment takes advantages of good temperature evenness, wide temperature adjustment range.
This series adopts high temperature circulating water as sterilization medium, and carry out water-pouring sterilizing operation for articles via warming up, sterilizing and cooling. The equipment takes advantages of good temperature evenness, wide temperature adjustment range. The sterilization medium works in a relatively closed circulation system, to avoid the secondary pollution in the work process. It is widely used for sterilization of infusion products, such as glass bottles, plastic bottles, soft bags and so on.
Common engineering parameter
| Steam pressure | 0.4~0.6Mpa | Design pressure | 0.17~0.3Mpa |
| Water pressure | 0.2~0.4Mpa | Working pressure | 0.15~0.27Mpa |
| Compressed air pressure | 0.5~0.7Mpa | Working temperature | 126℃ |
| Preset program | Glass bottle / Plastic bottle / Soft bag sterilization program and etc. | ||
Core Values
Material standard
| Part | Material | Part | Material |
| Chamber | SS304 | Chamber support | SS304 |
| Stiffener | Q245R | Pipelines | SS304 |
| Door base-plate | SS304 | Internal trolley | SS304 |
| Rack | SS304 | External trolley | SS304 |
| Door sealing gasket | Silicon rubber | Outer casing housing | SS304 |
Parameter & Size
| Model | Inner chamber size （L×Ф）mm | Overall size （L×W×H）mm Single/Double door | Net weight kg | Steam consumption kg/cycle | Control power AC220/50Hz/kw | Supply power 3-AC380/50Hz/kw | Water consumption kg/cycle | Cooling water consumption kg/cycle | Compressed air consumption m3/cycle |
| OSR-DKS-10 | 3160×Ф2000 | 3680×4100×2600 | 7000 | 650 | 0.5 | 15 | 1000 | 8000 | 12 |
| OSR-DKS-14 | 4260×Ф2000 | 4780×4100×2600 | 8000 | 800 | 0.5 | 15 | 1300 | 12000 | 17 |
| OSR-DKS-17 | 5260×Ф2000 | 5780×4100×2600 | 9000 | 1000 | 0.5 | 19 | 1600 | 15000 | 20 |
| OSR-DKS-22 | 6790×Ф2000 | 7310×4100×2600 | 11000 | 1200 | 0.5 | 22 | 2000 | 20000 | 25 |
| OSR-DKS-31 | 9860×Ф2000 | 10380×4100×2600 | 14500 | 1700 | 0.5 | 40 | 3000 | 28000 | 34 |
| OSR-DKS-35 | 10980×Ф2000 | 11500×4100×2600 | 16000 | 1850 | 0.5 | 45 | 3300 | 32000 | 39 |
| OSR-DKS-40 | 8360×Ф2500 | 8900×5200×3200 | 19000 | 2100 | 0.5 | 60 | 3500 | 38000 | 45 |
